FOUNDATIONS
DPS-1A FLASHER FOUNDATION
The Dixie Precast DPS-1A is a precast foundation that is commonly used for flasher or wayside signal applications. The S1 has a standard 9 ½” x 9 ½” bolt spacing, which matches the common mounting for 4” Mast junction box bases. Dixie Precast supplies the DPS-1A foundation pre-assembled, so it arrives at the job site ready to install. The S1 has lifting inserts cast in the top of the foundation, which facilitate the easy placement of the foundation. Dixie Precast utilizes the same thread on all of the lifting inserts throughout our product line, so the same lifting eyes can be utilized to set all of our foundations. The sectional construction of the foundations enables the foundation to be offered in various heights, with the most common supplied at 4’6”. Standard heights are available in 12” reductions or increases. The design of the S1 also allows for replacement of the top and/or bolts due to damage without removal of the entire foundation. The top section is designed to accommodate cable or duct entry into the mast and/or junction box. The Dixie Precast DPS-1A Foundation meets or exceeds current AREMA Standards.
DPS-2A GATE/WAYSIDE SIGNAL FOUNDATION
The Dixie Precast DPS-2A is a precast foundation commonly used for crossing gate mechanisms and wayside signal applications. The S2 has a standard 11 11/16” x 11 11/16” bolt spacing, which matches the common mounting for 5” masts.
Dixie Precast supplies the DPS-2A foundation pre-assembled, so it arrives at the job site ready to install. The S2 has lifting inserts cast into the top of the foundation, facilitating easy placement. Dixie Precast uses the same thread on all lifting inserts across our product line, so the same lifting eyes can be used to set all of our foundations.
The sectional construction of the foundations enables the foundation to be offered in various heights, with the most common supplied at 5’7”. In the event of damage to the top or bolts, the S2 design allows replacement of the damaged parts without removing the entire foundation. The top section is designed to accommodate cable or duct entry into the mast and/or junction box. The Dixie Precast DPS-2A Foundation meets or exceeds current AREMA Standards.
TF-2A 4X4 COMMUNICATION TOWER FOUNDATION
The Dixie Precast TF-2A 4X4 is a precast foundation that is commonly used for communication tower applications. The TF-2A has a standard 11 11/16” x 11 11/16” bolt spacing, which matches the common mounting for 5” masts. The foundation can be used with tilt tower or monopole applications. Dixie Precast supplies the TF-2A foundation pre-assembled, so it arrives at the job site ready to install. The foundation has lifting inserts cast into the top section, which facilitate easy placement. Dixie Precast uses the same thread on all lifting inserts across our product line, so the same lifting eyes can be used to set all of our foundations. The TF-2A can also be utilized for solar array mounting, column support, and other applications. The sectional design allows us to supply the foundation in various heights, ensuring it is sized to meet your loading requirements. The Dixie Precast TF-2A 4X4 Foundation meets or exceeds current AREMA Standards.
DP-4B SINGLE MAST CROSSING CANTILEVER FOUNDATION
The Dixie Precast DP-4B is a precast foundation commonly used for single-mast, four-bolt crossing gate cantilever applications. The 4B has a standard four-bolt mounting pattern of 19” x 19”. The load capacity of the DP-4B will handle single mast cantilevers up to 28’ – 30’ in arm length. Dixie Precast supplies the DP-4B as a sectional foundation for quick, simple field assembly. The DP-4B pieces have either lifting inserts or lifting hooks cast in place, facilitating easy placement of the foundation pieces. Dixie Precast uses the same thread on all lifting inserts across our product line, so the same lifting eyes can be used to set all of our foundations. The sectional construction of the foundations ensures that the maximum weight of each piece is well within the lifting capacity of standard construction equipment. The sectional design also allows damaged parts, such as the top or bolts, to be replaced individually without removing the entire foundation. The Dixie Precast DP-4B Foundation meets or exceeds current AREMA Standards.
DP-8B DOUBLE MAST CROSSING CANTILEVER FOUNDATION
The Dixie Precast DP-8B is a precast foundation that is commonly used for double-mast, four-bolt crossing gate cantilever applications. The 8B has a standard eight-bolt mounting pattern of 19” x 19” at 36” mast centers. The load capacity of the DP-8B will handle double mast crossing cantilevers from 30’ – 44’ in arm length. Dixie Precast supplies the DP-8B as a sectional foundation for quick, simple field assembly. The DP-8B pieces have either lifting inserts or lifting hooks cast in place, facilitating easy placement of the foundation pieces. Dixie Precast uses the same thread on all lifting inserts across our product line, so the same lifting eyes can be used to set all of our foundations. The sectional construction of the foundations ensures that the maximum weight of each piece is well within the lifting capacity of standard construction equipment. The sectional design also provides for damaged parts, such as the top or bolts, to be replaced individually without removing the entire foundation. The Dixie Precast DP-8B Foundation meets or exceeds current AREMA Standards.
DP-16B SERIES WAYSIDE CANTILEVER SIGNAL FOUNDATION
The Dixie Precast DP-16B series are precast foundations that are commonly used for four-mast wayside signal cantilever applications. The 16B has a standard sixteen bolt mounting pattern of 19” x 19” at 48” x 48” mast centers. Dixie Precast supplies the DP-16B foundations in sectional format for quick, simple field assembly. The DP-16B pieces have either lifting inserts or lifting hooks cast in place, facilitating easy placement of the foundation pieces. Dixie Precast uses the same thread on all lifting inserts across our product line, so the same lifting eyes can be used to set all of our foundations. The sectional construction of the foundations ensures that the maximum weight of each piece is well within the lifting capacity of standard construction equipment. The sectional design also allows damaged parts, such as the top or bolts, to be replaced individually without removing the entire foundation. The foundation design will enable it to accommodate cantilever lengths varying with the structure’s loading. The Dixie Precast DP-16B Foundations meet or exceed current AREMA Standards.
DPS-16H/DPS-90 SIGNAL BRIDGE FOUNDATION
The Dixie Precast DPS-16H and the DPS-90 series are precast foundations that are commonly used for wayside signal bridge applications. The 16H/S90 has a standard eight-bolt mounting pattern of 19” x 19” on 67” mast centers. Dixie Precast supplies bridge foundations in sectional format for quick, simple field assembly. The pieces have either lifting inserts or lifting hooks cast in place, which facilitate the easy placement of the foundation pieces. Dixie Precast uses the same thread on all lifting inserts across our product line, so the same lifting eyes can be used to set all of our foundations. The sectional construction of the foundations ensures that the maximum weight of each piece is well within the lifting capacity of standard construction equipment. The sectional design also allows damaged parts, such as the top or bolts, to be replaced individually without removing the entire foundation. The foundation design will enable it to accommodate the various lengths of bridge structures, depending on the structure’s loading. Contact Dixie Precast for assistance in sizing the foundation for the structure. The Dixie Precast DPS-16H and DPS-90 Series Foundations meet or exceed current AREMA Standards.
ANCHORS
DA-10 HELICAL ANCHORS
The Dixie Precast Concrete DA-10 Helical Anchor offers a simple alternative to traditional foundations for communication towers, gate mechanisms, and wayside signal mast applications. The helical foundations are installed in a matter of minutes with auger-type equipment. The Kelly Bar Adapter is placed on the equipment’s kelly bar and attached to the top of the foundation. After securing the foundation to the adapter, the foundation is screwed into the ground. The pilot point and helix of the foundation facilitate quick, easy installation. With a few checks for level during the installation, the process is completed in a fraction of the time when compared to traditional foundations. The simple installation reduces associated labor costs. The foundations are constructed entirely of galvanized steel. The Helical Foundations are offered in 5’, 7’, and 10’ lengths, all with standard 11 11/16” x 11 11/16” bolt spacing. Each foundation is supplied with 1” x 8” bolts, leveling nuts, and associated hardware. Special sizes and applications are also available. The Dixie Precase DA-10 Helical Anchors meet or exceed current AREMA Standards.
RETAINING WALLS
STEEL RETAINING WALL
The Dixie Precast Steel Retaining Wall is the most versatile and easiest to install retaining wall available. The walls are composed of galvanized steel panels that are available in 2’, 4’, and 6’ heights. All panels come in 5’ lengths. Designed for durability and long-term installation, all posts and associated hardware are also made of galvanized steel. Dixie Precast packages the walls with all required installation parts, including anchors, cables, clamps, and related hardware. The steel retaining wall is assembled similarly to a door hinge. Each panel has a hinge portion with interlocking “hinge” pipes on both ends. When assembled, the panels are pinned together by the post. The hinge effect allows the wall to be contoured as required. Recommended installations are applicable in both convex and concave arrangements. To ensure proper retainage and support, all procedures should be followed, including installation of anchors and back supports. Installation heights of over 6’ shall be installed with a tiered approach. Recommended wall separation for tiered applications shall be approximately 2’ – 4’ between wall locations. Contact us with any questions concerning fitting the Dixie Precast Steel Retaining Wall to your situation.
CONCRETE RETAINING WALL
The Dixie Precast Concrete Retaining Wall provides a durable system made of precast concrete panels and galvanized steel hardware, offering long-lasting durability. Panels are 2’ high by 4’ wide and can be ordered in 4’ increments, with heights of 2’, 4’, or 6’. Dixie Precast supplies all installation parts, including anchors, cables, clamps, and hardware. Configurable in straight sections, or 45° and 90° turns, these walls can be arranged to fit site needs, suitable for convex and concave installations. Follow all procedures for proper support, especially for heights over 6’, which require tiered installation with 2’ – 4’ separations. Contact us with questions about fitting the system to your site.
SPECIAL APPLICATIONS
With over 60 years of proven performance in the American rail industry, Dixie Precast delivers foundation solutions that are built for reliability, safety, and long-term service. Our team has refined and adapted our precast foundation expertise to meet demanding applications, including Above Ground Tower Foundations, Modified Cantilever Foundations, Hydrogen Cell Enclosure Foundations, Generator Pad Foundations, Specialized House Platform Foundations, Slide Fence Foundations, Avalanche Detector Foundations, and Solar Array Foundations. If you have a unique or specialized foundation requirement, our engineers will work with you to develop a dependable, cost-effective solution tailored to your project.
